Power Shelves & Racks
Attending to your high-performance computing needs, our AC-DC power shelves provide 12V and 48V output options, while our DC-DC power shelves feature 12V output solutions with -48V DC input. Complementing these are our robust racks, engineered to support and optimize the performance of our power shelves.
.png)
Blog Post
5 Critical Power Supply Challenges in Industrial Automation
Learn about common challenges faced by industrial automation systems and how the right power supply can help solve them
Read Blog Post
Blog Post
Power Supply Back Pressures in Applications
Ensure optimal PSU airflow and selection with Bel Power Solutions' strategies for effective power supply cooling.
Read Blog PostAttribute Filters
Product Type
Power (W)
Input Voltage Range (VAC)
Input Voltage Range (VDC)
Output Voltage (VDC)
Output Current (A)
Input Configuration
Configuration (max no. of PSUs)
Operating Temperature Range (ºC)
Dimensions LxWxH (mm)
No. of Output Busbars
NAC Included
| Product | Power (W) | Input Voltage Range (VAC) | Input Voltage Range (VDC) | Output Voltage (VDC) | Output Current (A) | Input Configuration | Configuration (max no. of PSUs) | No. of Output Busbars |
|---|---|---|---|---|---|---|---|---|
| 5000 | 90 ~ 264 | N/A | 12 ~ 48 | 105 ~ 417 | 1-Phase | 5 | 2 (Straight Short) | |
| 14400 | 200 ~ 480 | 240 ~ 380 | 12 | 1171 | 1-Phase, 3-Phase DELTA, 3-Phase WYE | 3+3, 5+1 | 1 (Offset Short), 1 (Straight Short), 3 (Straight Short) | |
| 14400 | N/A | -40 ~ -72 | 12 | 1171 | 1-Phase | 3+3, 5+1 | 1 (Offset Short), 1 (Straight Short), 3 (Straight Short) | |
| 19450 ~ 24060 | 200 ~ 480 | N/A | 54.5 | 352 ~ 440 | 1-Phase, 3-Phase WYE | 5+1, 6+0 | 1 (Offset Long), 1 (Offset Short), 1 (Straight Long), 3 (Straight Long) | |
| 28860 | 208 ~ 480 | N/A | 50 | 440 | 1-Phase, 3-Phase WYE | 3+3, 5+1 | 1 (OrV3) |
Datasheet
