SMD Inductors
Engineered for high-density applications, our SMD inductors offer compact and efficient solutions that fit flawlessly in crowded PCB layouts. Available in open frame or shielded constructions, these inductors are ideal for consumer electronics and compact space designs.
Product Resources
Blog Post
Selecting Surface Mount Inductors For DC to DC Converter Applications
Inductor Chokes/Coils
Get the most from your DC to DC Converters with our guide to selecting the right surface mount inductors.
Read Blog PostAttribute Filters
Inductance (uH)
Current (A)
Current Saturation - Isat (A)
DCR (Ohm)
Test Frequency (KHz)
Length (mm)
Width (mm)
Height (mm)
Shielding
Operating Temperature (ºC)
Packaging
AEC-Q200 Compliant
147 Products
| Product | Inductance (uH) | Current (A) | Current Saturation - Isat (A) | DCR (Ohm) | Height (mm) | Shielding | Operating Temperature (ºC) |
|---|---|---|---|---|---|---|---|
| 1.2 ~ 47 | 0.25 ~ 1.1 | 0.23 ~ 1.1 | 117 ~ 1820 | 1.2 ~ 1.8 | Yes | -40 ~ +105 | |
| 1 ~ 47 | 0.3 ~ 1.9 | 0.28 ~ 2 | 78 ~ 1262 | 1.2 ~ 1.8 | Yes | -40 ~ +105 | |
| 1 ~ 47 | 0.4 ~ 1.75 | 0.32 ~ 3 | 75 ~ 1710 | 1.2 ~ 1.5 | Yes | -40 ~ +105 | |
| 0.1 ~ 10 | 1 ~ 7 | 1 ~ 8 | 13 ~ 660 | 0.8 ~ 1 | Yes | -55 ~ +125 | |
| 0.1 ~ 10 | 0.7 ~ 10 | 0.9 ~ 11.5 | 6 ~ 800 | 0.8 ~ 1.2 | Yes | -55 ~ +125 | |
| 0.1 ~ 10 | 0.95 ~ 10.5 | 1.4 ~ 12.5 | 10 ~ 560 | 0.8 ~ 1.2 | Yes | -55 ~ +125 | |
| 0.1 ~ 10 | 1.6 ~ 11 | 1.8 ~ 16.5 | 7 ~ 365 | 1 ~ 1.2 | Yes | -55 ~ +125 | |
| 0.47 ~ 33 | 2.6 ~ 15 | 3.6 ~ 24 | 0.0042 ~ 0.2 | 2.8 ~ 3.8 | Yes | -55 ~ +155 | |
| 0.0039 ~ 10 | 0.17 ~ 1 | N/A | 0.05 ~ 8.6 | 2.25 | No | -40 ~ +125 | |
| 0.12 ~ 22 | 0.7 ~ 12 | 1.2 ~ 24 | 4.2 ~ 430 | 0.8 ~ 1.8 | Yes | -40 ~ +125 | |
| 1 ~ 47 | 0.35 ~ 1.8 | 0.25 ~ 2.1 | 65 ~ 1625 | 1 ~ 1.5 | Yes | -40 ~ +125 | |
| 1 ~ 47 | 0.32 ~ 1.6 | 0.28 ~ 3.5 | 60 ~ 1440 | 1.2 ~ 1.8 | Yes | -40 ~ +125 | |
| 1.2 ~ 100 | 0.35 ~ 1.9 | 0.28 ~ 2.4 | 65 ~ 2065 | 1.2 ~ 1.5 | Yes | -40 ~ +125 | |
| 1 ~ 39 | 0.33 ~ 1.9 | 0.46 ~ 2.6 | 78 ~ 1812 | 1 ~ 1.5 | No | -40 ~ +105 | |
| 1 ~ 56 | 0.32 ~ 2.3 | 0.4 ~ 3.6 | 64 ~ 1920 | 1.2 ~ 1.8 | No | -40 ~ +105 | |
| 1 ~ 47 | 0.35 ~ 2.5 | 0.42 ~ 4 | 66 ~ 1730 | 1.2 ~ 1.5 | No | -40 ~ +105 | |
| 0.24 ~ 0.47 | 3.3 ~ 3.7 | 4.2 ~ 5.7 | 27 ~ 35 | 0.8 | Yes | -55 ~ +125 | |
| 0.22 ~ 1 | 1.8 ~ 3 | 2.3 ~ 5 | 40 ~ 200 | 0.8 | Yes | -55 ~ +125 | |
| 0.1 ~ 6.8 | 3 ~ 13.5 | 3 ~ 33 | 2.42 ~ 74.1 | 2.1 ~ 3 | Yes | -55 ~ +125 | |
| 0.15 ~ 22 | 2.5 ~ 14.3 | 3 ~ 32.5 | 2.31 ~ 99.65 | 2.1 ~ 5 | Yes | -55 ~ +125 | |
| 0.18 ~ 22 | 3.8 ~ 24 | 4.8 ~ 36 | 1.75 ~ 60.63 | 3.1 ~ 6 | Yes | -55 ~ +125 | |
| 0.27 ~ 8.2 | 3 ~ 20 | 8 ~ 31.8 | 2.81 ~ 48.73 | 2.1 ~ 7 | Yes | -55 ~ +125 | |
| 1.8 ~ 10 | 6.6 ~ 18 | 8.5 ~ 22.5 | 4 ~ 22.9 | 8 | Yes | -55 ~ +125 | |
| 0.28 ~ 15 | 8.7 ~ 25.5 | 11 ~ 55 | 1.5 ~ 19.3 | 3.1 ~ 10 | Yes | -55 ~ +125 | |
| 4.7 ~ 33 | 8.6 ~ 23 | 13 ~ 39 | 3.3 ~ 22.2 | 10 ~ 13 | Yes | -55 ~ +125 |
Datasheet
