HP4660-9RG

DC-DC Rugged Melcher™ Cassette | Power 120W | Output 24/24/24/24VDC, 1.25/1.25/1.25/1.25A | Input 16.8-137.5VDC | Output voltage control input | RoHS Compliant

Email Form

DC-DC Rugged Melcher™ Cassette | Power 120W | Output 24/24/24/24VDC, 1.25/1.25/1.25/1.25A | Input 16.8-137.5VDC | Output voltage control input | RoHS Compliant

Email Form

Email Form

Power (W) 120
Output Voltage (VDC) 24/24/24/24
Output Current (A) 1.25/1.25/1.25/1.25
Voltage Input (VDC) 16.8-137.5
Operating Temperature (ºC) -40 to 71
Isolation Isolated
Mounting Type Chassis Mount
Dimension 3U / 4HP cassette
Number of Outputs 4
Vout 1 (VDC) 24
Vout 2 (VDC) 24
Vout 3 (VDC) 24
Vout 4 (VDC) 24
Iout 1 (A) 1.25
Iout 2 (A) 1.25
Iout 3 (A) 1.25
Iout 4 (A) 1.25
Auxiliary functions and options Output voltage control input
RoHS RoHS Compliant
