3D View
HCTI-390-5.0
Through Hole Inductors
Unshielded High Current Toroidal Inductor, 390 uH, 5 A, 0.072 Ω DCR
Stock Check
Country - USA
Features & Specifications
| Inductance (µH) | 390 |
| Current (A) | 5 |
| DCR (Ohm) | 0.072 |
| Operating Temperature (ºC) | -55 ~ +105 |
| Inductance @ Rated Current (uH) | 200.2 |
| Length (mm) | 32.5 |
| Width (mm) | 16.5 |
| Mounting Type | Through Hole Mount |
| Height (mm) | 32.5 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Shielding | Yes |
| Brand | Signal Transformer |
