CPD Series
CPD Series

DATASHEET


CPD Series

Share

The CPD Series from Bel Power Solutions is a family of DC-DC CompactPCI devices, available in a 3U form factor, provides excellent thermal performance for very reliable power over a wide range of input voltage. The CPD Series offers higher output currents than other similarly rated products.

Specifications

  • Wide range DC or AC input with PFC
  • Extremely high efficiency and high power density
  • 4 high current outputs with flexible load distribution
  • Single-wire current share function for 3 outputs
  • 47 pin connector, type Positronic

Features

  • RoHS lead-free-solder and lead-solder-exempted products available
  • Compliant to PICMG® CompactPCI® specifications
  • Integrated ORing FETs / diodes for true redundancy
  • Inhibit and enable inputs
  • Remote sense lines
  • Hot-swap capability

Datasheets and Drawings

Data Sheet CPA / CPD Series Data Sheet

Email Form

SPECIFICATIONS

The CPD Series from Bel Power Solutions is a family of DC-DC CompactPCI devices, available in a 3U form factor, provides excellent thermal performance for very reliable power over a wide range of input voltage. The CPD Series offers higher output currents than other similarly rated products.

Specifications

  • Wide range DC or AC input with PFC
  • Extremely high efficiency and high power density
  • 4 high current outputs with flexible load distribution
  • Single-wire current share function for 3 outputs
  • 47 pin connector, type Positronic

Features

  • RoHS lead-free-solder and lead-solder-exempted products available
  • Compliant to PICMG® CompactPCI® specifications
  • Integrated ORing FETs / diodes for true redundancy
  • Inhibit and enable inputs
  • Remote sense lines
  • Hot-swap capability
