FNP600/850/1000 (AC-DC)
FNP600/850/1000 (AC-DC)

DATASHEET


FNP600/850/1000 (AC-DC)

Share

The Bel Power Solutions flexible output power FNP 600/850 Series, blends high power densities between 10.5 and 16.1 W/in3and a wide input voltage range of 90 to 264 VAC, with 1U or 2U configurability, I2C management features, hot-swap and 90% efficiency, can support the demands of telecom, datacom and other distributed power uses.The FNP600/850 series is also available as a DC model, offering a wide DC input voltage range of 36 to 75VDC.

Specifications

  • High density front-ends 10.5 to 16.1 W/in3
  • Universal input voltage range (90-264 VAC) with PFC
  • 1U or 2U height configurations
  • Standby voltage of 12 VDC @ 0.5 A

Features

  • Droop current share with ORing FETs
  • I2C interface status and control
  • Overtemperature, overload, and overvoltage protection
  • Status LEDs: AC OK, DC OK, Overtemperature
  • ON/OFF Enable switch - shuts OFF Vo1; Vaux and fan are operational.

Datasheets and Drawings

Data Sheet FNP600/850/1000 (AC-DC )Datasheet

Email Form

SPECIFICATIONS

The Bel Power Solutions flexible output power FNP 600/850 Series, blends high power densities between 10.5 and 16.1 W/in3and a wide input voltage range of 90 to 264 VAC, with 1U or 2U configurability, I2C management features, hot-swap and 90% efficiency, can support the demands of telecom, datacom and other distributed power uses.The FNP600/850 series is also available as a DC model, offering a wide DC input voltage range of 36 to 75VDC.

Specifications

  • High density front-ends 10.5 to 16.1 W/in3
  • Universal input voltage range (90-264 VAC) with PFC
  • 1U or 2U height configurations
  • Standby voltage of 12 VDC @ 0.5 A

Features

  • Droop current share with ORing FETs
  • I2C interface status and control
  • Overtemperature, overload, and overvoltage protection
  • Status LEDs: AC OK, DC OK, Overtemperature
  • ON/OFF Enable switch - shuts OFF Vo1; Vaux and fan are operational.
