PSB Series

Share

The PSB Series highly efficient power up to 96% over its 8 to 144 VDC input voltage range, as well as a maximum of 6A output power, delivered by a single output. This series has no derating over temperature and low input-output voltage differential.

Specifications

  • Input voltage up to 144 VDC
  • Single output of 5.1 to 48 VDC
  • High efficiency up to 96%
  • Extremely wide input voltage range

Features

  • No input-to-output isolation
  • Low input-to-output differential voltage
  • Input undervoltage lockout
  • Output voltage adjustment and inhibit function
  • Continuously no-load and short-circuit proof

Email Form

The PSB Series highly efficient power up to 96% over its 8 to 144 VDC input voltage range, as well as a maximum of 6A output power, delivered by a single output. This series has no derating over temperature and low input-output voltage differential.

Specifications

  • Input voltage up to 144 VDC
  • Single output of 5.1 to 48 VDC
  • High efficiency up to 96%
  • Extremely wide input voltage range

Features

  • No input-to-output isolation
  • Low input-to-output differential voltage
  • Input undervoltage lockout
  • Output voltage adjustment and inhibit function
  • Continuously no-load and short-circuit proof

Email Form

PSB Series

Part Number Distributor Stock Drawing/Datasheet 3D Model Sample Request Power (W)Output Voltage (VDC)Output Current (A)Voltage Input (VDC)Operating Temperature (°C)IsolationDimension
PSB5A7-9LIRG cancel
3D Icon 355.177-40-40 to 71Non-Isolated105.9 x 69.1 x 32.3
PSB125-9IRG check_circle
3D Icon Sample Request Icon 6012515-80-40 to 71Non-Isolated105.9 x 69.1 x 32.3
PSB5A7-9LIPCG cancel
3D Icon 355.177-40-40 to 71Non-Isolated105.9 x 69.1 x 32.3
PSB5A7-9LIRCG cancel
3D Icon 355.177-40-40 to 71Non-Isolated105.9 x 69.1 x 32.3
PSB126-2 cancel
3D Icon 7212615-40-10 to 50Non-Isolated105.9 x 69.1 x 32.3
PSB243-9IRG cancel
3D Icon 7224331-144-40 to 71Non-Isolated105.9 x 69.1 x 32.3
PSB123-9IRG cancel
3D Icon 3612318-144-40 to 71Non-Isolated105.9 x 69.1 x 32.3
